Primary Energy Efficiency


Classification:
Features
This product is primary energy efficiency certified by China government.
Main Equipments
1、high efficiency PV modules with ULCE\TUV certificate
2、water heater
3.enamel water tank
4、controller
Specification Parameters
Specification | GFR-60 | GFR-80 | GFR-100 | GFR-120 | GFR-150 |
Capacity | 60L | 80L | 100L | 120L | 150L |
Photovoltaic panel power | 550W | 550W | 670W | 900W | 1180W |
Photovoltaic panel size | 1722*1134*30mm | 2278*1134*30mm | 2384*1303*30mm | 1722*1134*30mm*2 | 2278*1134*30mm*2 |
Time required for | 4hours(Under sufficient lighting conditions) | ||||
Maximum input power of photovoltaic panel | 48∨/25℃ | ||||
Ac heating power | 2000W | ||||
AC rated voltage | 220V | ||||
Temperature Adjustment Range | 30°℃ 70°℃ | ||||
Water tank liner material | Enamel iner | ||||
Net Dimensionl | φ 468*745mm | φ468*893mm | φ470*1140mm | φ470*1251mm | φ480*1380mm |
Note:Product parameters for reference only specific product nameplate based |

Keywords:Primary Energy Efficiency
