Largeflat Panel Solar Collector
Keywords:
Eva Solid Mat
Eva Jigsaw Puzzle Series
- 产品描述
-
Features
·Copper tube.
·Reflection reduction glass.
·Efficient blue aluminum plate.
·The collector reduces by half of land ccupation.
Specification Parameters
Gross area 15.02m² Aperture area 13.95m² Outline size(Unit：mm) 5960×2520x130/ 5960×2520×160 Machine weight ~307kg Material of cover plate Ultra-white linen finish toughened glass Number of cover plate single layer 3.2mm Material of plate aluminum 0.4mm, blue film imported from Almeco in Germay Material of insulation 60mm high density glass fiber cotton and double-sided aluminum foil put on the bottom. Glass fiber cotton with aluminum foil 26mm put on the sides. Pieces of copper pipe 24 pieces Size of copper pipe φ8×0.4mm Main runner φ42×1mm The fluid volume inside the collector 11.82L Design pressure 10bar Experimental pressure 16bar Connector KF connector DN40
With advanced flat plate solar collectors and enameled water tanks and air energy products all industry chain production line, is a large domestic vacuum tube solar energy production base.
Certifications we have received
Since the establishment of the company, Muyang people always strive for excellence in enterprises and products, and has won the honors of high-tech enterprises, Shandong famous brand, home appliances to the countryside in the bidding brand, energy-saving products to benefit the people's project in the bidding enterprise, the provincial level of the contract and trustworthy enterprises, and has successfully passed the certification of IS09001, ISO14001, IS018001, the National Compulsory 3C certification, the CQC Golden Sun certification, the National Product Leader certification, the National Healthy Living Certification, China Ten Ring Certification, China Energy Conservation Certification, China Environmental Protection Certification, all products have passed the national and provincial laboratory inspection. Product Leader Certification, National Habitat Certification, China Ten Ring Certification, China Energy Conservation Product Certification, China Environmental Protection Product Certification, etc. All products have passed the national and provincial laboratory inspection.
